There are two parts that are covered:
- Weekly average of PM10 Measurement using GAM
- Understanding GPS data
According to the Datacamp course, a generalized additive model (GAM) is "a generalized linear model in which the linear predictor depends linearly on unknown smooth functions of some predictor variables, and interest focuses on inference about these smooth functions."
It is worthwhile to use this approach because the smoothing functions of geo-environmental elements (e.g. DEM, XY coordinates, land use, buildings) might explain the complexity of pollution flow. In R CRAN, there are two packages called called MAPGAM and mgcv. MAPGAM (Mapping Smoothed Effect Estimates from Individual-Level Data) uses GAM for mapping odds ratios, other effect estimates using individual-level data such as case-control study data, while mgcv focuses on the mathematical perspective of GAM. After trying both, I decided to use mgcv for its miscellaneous applications e.g. convert to raster, analyse GIS files without pre-processing effort (MAPGAM does need some effort to bring shapefiles).
Wiki says...
The model relates a univariate response variable, Y, to some predictor variables, xi. An exponential family distribution is specified for Y (for example normal, binomial or Poisson distributions) along with a link function g (for example the identity or log functions) relating the expected value of Y to the predictor variables via a structure such as
The functions fi may be functions with a specified parametric form (for example a polynomial, or an un-penalized regression spline of a variable) or may be specified non-parametrically, or semi-parametrically, simply as 'smooth functions', to be estimated by non-parametric means. So a typical GAM might use a scatterplot smoothing function, such as a locally weighted mean, for f1(x1), and then use a factor model for f2(x2). This flexibility to allow non-parametric fits with relaxed assumptions on the actual relationship between response and predictor, provides the potential for better fits to data than purely parametric models, but arguably with some loss of interpretability.
https://en.wikipedia.org/wiki/Generalized_additive_model
Here is the weekly Average data shown in a data table. Click to enlarge image
Note that pm2013_XX refers to:
pm2013_30: 2013 July week 4pm2013_31: 2013 August week 1pm2013_32: 2013 August week 2pm2013_33: 2013 August week 3pm2013_34: 2013 August week 4pm2013_35: 2013 September week 1pm2013_36: 2013 September week 2pm2013_37: 2013 September week 3pm2013_38: 2013 September week 4pm2013_39: 2013 September week 5
Here is a map of 46 stations considered in this study
I tested the GAM equation by using gam() function. The basic approach is to put the smoothing argument s() to the relevant variables. In my case, I put the s(X,Y) XY coordinates together as an interaction factor, and add a DEM smoother s(DEM).
The "method = REML" is a mathematical option that is used as default. From stackoverflow, REML is an acronym of REstricted Maximum Likelihood. Here is one of the online user's comments:
Indeed, the REML estimator of a variance component is usually (approximately) unbiased, while the ML estimator is negatively biased. However, the ML estimator usually has lower mean-squared error (MSE) than the REML estimator. So, if you want to be right on average, go with REML, but you pay for this with larger variability in the estimates. If you want to be closer to the true value on average, go with ML, but you pay for this with negative bias.
Since we have only 46 stations, I will leave the method as REML.
jul.w4 <- gam(pm2013_30 ~ s(X, Y) + s(DEM), data = aq.pm10, method = "REML")
aug.w1 <- gam(pm2013_31 ~ s(X, Y) + s(DEM), data = aq.pm10, method = "REML")
aug.w2 <- gam(pm2013_32 ~ s(X, Y) + s(DEM), data = aq.pm10, method = "REML")
aug.w3 <- gam(pm2013_33 ~ s(X, Y) + s(DEM), data = aq.pm10, method = "REML")
aug.w4 <- gam(pm2013_34 ~ s(X, Y) + s(DEM), data = aq.pm10, method = "REML")
sep.w1 <- gam(pm2013_35 ~ s(X, Y) + s(DEM), data = aq.pm10, method = "REML")
sep.w2 <- gam(pm2013_36 ~ s(X, Y) + s(DEM), data = aq.pm10, method = "REML")
sep.w3 <- gam(pm2013_37 ~ s(X, Y) + s(DEM), data = aq.pm10, method = "REML")
sep.w4 <- gam(pm2013_38 ~ s(X, Y) + s(DEM), data = aq.pm10, method = "REML")
sep.w5 <- gam(pm2013_39 ~ s(X, Y) + s(DEM), data = aq.pm10, method = "REML")Here is the R2 of each model:
- July w4: .25
- August w1: .23
- August w2: .204
- August w3: .077
- August w4: .232
- September w1: .16
- September w2: .292
- September w3: .208
- September w4: .346
- September w5: .327
The default model used gaussian distribution for model fitting. However, we can change the options as mentioned below:
binomial(link = "logit")gaussian(link = "identity")Gamma(link = "inverse")inverse.gaussian(link = "1/mu^2")poisson(link = "log")quasi(link = "identity", variance = "constant")quasibinomial(link = "logit")quasipoisson(link = "log")
All options need further investigation, but so far, inverse.gaussian(link = "1/mu^2") got the highest R2 value. For example, September w5 was increased to .392.
Now we got all the GAM models ready. But how will the model be translated to a map? The answer is to build a grid. As a start, I used 200 x 200 x 200 grid area of X, Y, Z(DEM).
According to Simon Wood's book "Generalized Additive Model 2nd Edition 2017", he noted that the model containing more than one smoothing function(e.g. f(x), f(y)) are only estimable within the additive constant. I will come back to that later, but so far, adding DEM into the model increased the R2. Click to enlarge image
Here is an example of the GPS data. As can be seen below, there are 13 columns in total and all measurements are taken every minute.
| period | who | group | loc1 | loc1_1 | time | pm10 | pm2_5 | pm1 | long | lat | X | Y |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 2 | 1 | 2 | 1 | 32 | 2013-07-25 20 | 57 | 104.6 | 97 | 89.7 | 126.9822844 | 37.31476048 | 198429.6307 |
| 2 | 1 | 2 | 1 | 32 | 2013-07-25 20 | 48 | 106.6 | 83 | 78.2 | 126.9822908 | 37.31488669 | 198430.1956 |
Here is a brief code info. I removed data from the pilot study.
- Period
- Pilot: 1
- Summer: 2
- Winter: 3
- who: researcher 1-5
- group: cluster 1-9
- loc1(location category)
- indoors(no movement): 1
- outdoors(no movement): 2
- movement: 3
- loc1_1(specific location)
- Restaurant: 10
- Coffee shop: 11
- Bbq grill: 12
- Bar: 13
- Office: 14
- Traditional market: 15
- Superstore: 16
- Department store: 17
- Shopping complex: 18
- Other shops(including convenience store): 19
- Workplace: 20
- Bank: 21
- School: 22
- Academy(educational): 23
- Bookshop: 24
- Rest centre for seniors: 25
- Stroll: 26
- Walking: 27
- Bus: 28
- Subway: 29
- Taxi: 30
- Personal vehicle: 31
- At home: 32
- Missing data: 999
This GPS track plot is derived from one researcher who commutes from Suwon to Seoul (1.5 hour distance).
Click to enlarge image.
- July (count by minutes)
PM10 < 50 < 100 < 150 < 200 > 200
0 147 113 40 0 0
1 115 96 28 0 1
2 120 102 18 0 0
3 140 87 12 0 1
4 122 60 58 0 0
5 124 59 57 0 0
6 121 92 27 0 0
7 112 68 60 0 0
8 88 89 63 0 0
9 96 121 19 2 2
10 85 148 5 0 0
11 63 151 7 3 0
12 116 90 20 1 0
13 81 69 9 0 0
14 26 126 6 0 0
15 60 118 2 0 0
16 69 67 0 0 0
17 120 60 0 0 0
18 155 37 1 0 0
19 167 10 2 0 1
20 140 66 3 0 0
21 119 121 25 5 0
22 136 117 47 0 0
23 161 116 23 0 0
- August (count by minutes)
PM10 < 50 < 100 < 150 < 200 > 200
0 134 4 8 31 3
1 190 1 0 15 0
2 180 0 0 0 0
3 197 1 0 0 1
4 198 2 0 24 16
5 180 0 39 20 1
6 159 9 54 16 2
7 136 25 6 62 0
8 169 18 19 34 0
9 124 64 0 0 0
10 120 60 0 0 0
11 110 63 1 0 0
12 81 95 0 0 1
13 156 47 4 0 0
14 176 42 4 1 1
15 236 4 0 0 0
16 221 17 1 1 0
17 222 13 2 1 0
18 236 4 0 0 0
19 165 33 10 1 12
20 159 18 2 1 0
21 141 9 16 24 19
22 120 0 6 10 44
23 120 0 9 18 33
- September (count by minutes)
PM10 < 50 < 100 < 150 < 200 > 200
0 134 4 8 31 3
1 190 1 0 15 0
2 180 0 0 0 0
3 197 1 0 0 1
4 198 2 0 24 16
5 180 0 39 20 1
6 159 9 54 16 2
7 136 25 6 62 0
8 169 18 19 34 0
9 124 64 0 0 0
10 120 60 0 0 0
11 110 63 1 0 0
12 81 95 0 0 1
13 156 47 4 0 0
14 176 42 4 1 1
15 236 4 0 0 0
16 221 17 1 1 0
17 222 13 2 1 0
18 236 4 0 0 0
19 165 33 10 1 12
20 159 18 2 1 0
21 141 9 16 24 19
22 120 0 6 10 44
23 120 0 9 18 33
